RIGOL RSA804 REAL-TIME SPECTRUM ANALYZER

Overview

The RIGOL RSA804 Real-Time Spectrum Analyzer is expertly engineered to meet professional RF testing demands across wireless communications, IoT, automotive electronics, and laboratory environments. Utilizing RIGOL's custom-engineered hardware platform, this 4.5 GHz instrument delivers an exceptional measurement experience tailored for complex signal analysis, transient interference hunting, and high-precision debugging without compromising on test speed or accuracy.

Built for both stationary lab integration and dynamic field testing, the RSA804 combines a wide 5 kHz to 4.5 GHz frequency range with a maximum 40 MHz real-time analysis bandwidth. Highly integrated and weighing only 1.9 kg, its compact form factor and native Type-C power bank compatibility make it uniquely adapted for mobile operations and field deployments where traditional AC power is unavailable. With standard General-Purpose Spectrum Analysis (GPSA) and Real-Time Spectrum Analysis (RTSA) modes, the RSA804 ensures engineers can instantly isolate intermittent anomalies and gain actionable, deep signal insights.

Product Features

Professional Real-Time Performance

With a maximum 40 MHz real-time bandwidth and an outstanding FFT rate of up to 199,804 frames per second, the RSA804 excels at capturing transient, fast-hopping, or intermittent signals that traditional swept spectrum analyzers miss completely, achieving a 100% Probability of Intercept (POI) for signals down to 5.62 microseconds.

Multi-Mode Flexibility & Expandability

The architecture supports five distinct working modes to adapt to diverse testing criteria, providing comprehensive spectrum analysis, real-time capture, and vector signal validation to smoothly accelerate your workflow from basic signal observation to complex domain analysis.

Custom-Engineered Portability

Weighing a mere 1.9 kg with an ultra-slim depth of 77.38 mm, the RSA804 is an agile field asset. Its low-power design runs directly from a standard Type-C adapter or standard portable power bank, ensuring seamless field maintenance and drive-test capabilities without bulky equipment.

Advanced Built-in Tools

The instrument features a built-in tracking generator as standard, allowing for immediate scalar network analysis such as component, filter, and cable measurements. Signal visualization is optimized on a 7-inch capacitive multi-touch screen showing multi-pane windowed layouts for fast data correlation.

Technical Specifications

• Frequency Range: 5 kHz to 4.5 GHz

• Max. Real-Time Bandwidth: 40 MHz

• Standard Measurement Modes: General-Purpose Spectrum Analyzer (GPSA), Real-Time Spectrum Analyzer (RTSA)

• Optional Application Enhancements: Vector Signal Analysis (RSA800-VSA), EMI Measurement (RSA800-EMI), Analog Demodulation (RSA800-ADM), and Advanced Measurement Kit (RSA800-AMK)

• Displayed Average Noise Level (DANL): Normalized to 1 Hz, 1 GHz typical: -146 dBm with preamplifier off / -168 dBm with preamplifier on

• SSB Phase Noise (1 GHz Carrier): Less than -110 dBc/Hz at 10 kHz offset (-112 dBc/Hz typical)

• Resolution Bandwidth (RBW): 1 Hz to 10 MHz (1-3-10 sequence)

• Video Bandwidth (VBW): 1 Hz to 10 MHz (1-3-10 sequence)

• Tracking Generator Output: 100 kHz to 4.5 GHz, output level range from -40 dBm to 0 dBm

• 100% POI Minimum Signal Duration: 5.62 microseconds at maximum span

• Display Size and Type: 7-inch capacitive multi-touch HD display (1024x600 resolution), HDMI out for external monitor.

• Mass Memory: 32 GB internal storage, supports external USB storage devices

• Connectivity Interfaces: LAN (100/1000 Base-T, LXI Core 2011 Device), USB Type-A Host, USB Type-B Device, HDMI 1.4

• Power Parameters: Type-C interface, DC 20 V, 5 A input, 55 W typical consumption (supports external power banks)

• Dimensions (W x H x D): 265.35 mm x 161.75 mm x 77.38 mm

• Weight: 1.9 kg

Download Rigol RSA800 Datasheet
