Rigol DSG821 2,1GHz RF Signalgenerator

The Rigol DSG800(A) series delivers outstanding performance in the same class of economical RF signal sources with full frequency and power scanning capabilities, as well as AM/FM/ØM analog modulation, powerful pulse modulation and newly added IQ modulation.

Compared to similar products, the DSG800 (A) has the smallest footprint and superior portability, making it an excellent choice for educational laboratories, industrial production lines, development and research applications.

• Highly cost-effective economical RF signal generator
  • Frequency Range  9 kHz to 2,1 GHz
  • Frequency resolution 0.01 Hz
  • Up to -112 dBc/Hz (typical) phase noise
  • Up to +20 dBm (typical) maximum output power
  • Higher level of amplitude accuracy, up to 0.5 dB (typical)
  • Superb signal stability
• Functions almost matching those of high-level RF signal generators
  • Flexible frequency and amplitude sweep functions
  • Complete AM/FM/ØM analog modulation functions
  • Standard LF output function
  • Powerful pulse modulation function
  •  Open vector modulation function
  • System flatness calibration function
  • Simple and easy to operate
• Special design ensuring its reliability and durability
  • Use electronic attenuator to avoid wearing
  • Specially designed protection functions
  • Digital ALC circuit
  • Simple structure
• Smallest in size among the like products
  • Occupy the least workbench space
  • Occupy less rack space
  • Light weight

Download datasheet for Rigol DSG800(A) series RF Signal generator.
