Rigol DNA5042 5 kHz - 4.5 GHz, 2 ports Vector Network Analyzer

Rigol DNA5000 Vector Network Analyzer empowers you to precisely capture S-parameters, assessing your device's full transmission and reflection profile.

Effortlessly tackle impedance matching with intuitive Smith charts and polar plots, and rapidly diagnose cable and antenna issues using the powerful Distance-to-Fault (DTF) function.

• Frequency range: 5 kHz to 4.5 GHz
• Number of Ports: 2
• Frequency resolution 1 Hz
• Max. output power 10 dBm
• High dynamic range 127 dB (typ.)
• Trace noise: 0.005 dB
• IF BW: 1 Hz to 10 MHz
• Compatible with the mechanical calibration kit and the Ecal electronic calibration kit, supporting various calibration types (SOLT, Response Short, Response Open, OSL, Enhanced Response 1 to 2, Response Through)
• Integrates S-parameters, impedance, VSWR, TDA, fixture embedding/de-embedding, antennatest, and etc.
• Portable and light-weighted design, with the compact size of (358.1 mm x 214.8 mm x 121.4 mm) and light weight of 5.3 kg
• 10.1'' 1280x800 HD touch screen
• Supports LAN, USB Device, USB Host, and HDMI interfaces
• Supports standard SCPI instruction sets
• Supports Web Control for remote operation
• Supports both physical key operation and touch screen operation; allowing you to use externally connected keyboard and mouse to input values

Download Rigol DNA5042 Datasheet
