Rigol DHO4404 12-Bit 400MHz 4-kanals oscilloskop

kr 55 865,00 kr 44 692,00

DHO4000 series digital oscilloscope is a new high-resolution digital oscilloscope based on RIGOL's "Centaurus" chipset.

  • Promotion: MSO5000 option bundle included!
  • Based on the new Rigol "Centaurus" chipset
  • Bandwidth: 400 MHz, upgradable to 800MHz
  • 4 analog channels and 1 EXT channel
  • 12-bit vertical resolution
  • Real-time sample rate up to 4 GSa/s
  • Ultra-low noise floor at 18 μVrms in minimum
  • Memory Depth up to 500 Mpts (optional)
  • Min. vertical sensitivity: 100 μV/div
  • Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
  • 10.1'' 1280*800 HD touch display
  • User-friendly Flex Knobs, bringing smoother interaction
  • Standard photoelectric encoder operating knobs, effectively prolonging its service life
  • Standard USB Device & Host, LAN, and HDMI interfaces
  • Optional battery pack in a highly portable package for unlimited freedom
  • Support online version upgrade
Mer informasjon
Båndbredde400 MHz
Capture rate50,000 wfms/s, 1,500,000 wfms/s (UltraAcquire Mode)
Samplingshastighet4 GSa/s (single channel), 2 GSa/s (half channels), 1 GSa/s (all channels)
